MITSUBISHI OUTDOOR UNIT MXZ-3HA50 VF

€1.849,00

In stock

Split-unit 30000 BTU: No installation, Collection Head Office Tegelen

Quantity:

MXZ Basis Triple Multisplit outdoor unit 7.5 kW (R32)
Suitable for:
2x MSZ-HR35VF (3.5 kW)

1X MSZ-HR50VF (5.0)
1X MSZ-HR25VF (2.5)

SEER (cooling) 7.26

Energy efficiency class cooling

A++

Annual energy consumption cooling (Hce=350 hours - full load)

241 kWh

SCOP (heating)

4.02

Energy efficiency class heating

A+

Total cooling capacity

2.90 - 6.50 kW

Total heating capacity

2.60 - 7.50 kW

Connection voltage

230 V

Frequency

50 Hz

Number of phases

Power input for cooling

0.00 - 1.26 kW

Power input for heating

0.00 - 1.30 kW

Fuse protection (slow-blow)

25 A

Refrigerant type

R32

Refrigerant quantity

1.4 kg

Max. height difference

15 m

Operating temperature cooling (Dry Bulb)

-10.00 - 46.00 °C

Operating temperature heating (Wet Bulb)

-15.00 - 24.00 °C

Number of cooling circuits (compressors)

Min. pipe length per circuit

0 m

Max. pipe length per circuit

25 m

Max. total pipe length

50 m

Nom. liquid line diameter

1/4"

Nom. suction line diameter

3/8"

External pipe diameter liquid line

6.35 mm

External pipe diameter suction line

9.52 mm

57 kg

840 mm

710 mm

330 mm

MITSUBISHI OUTDOOR UNIT MXZ-3HA50 VF

€1.849,00

Product Information

Product information

MXZ Basic Triple Multi-split outdoor unit 5.0 kW (R32) Suitable for: 2x MSZ-HR35VF (3.5 kW) 1X MSZ-HR50VF (5.0) 1X MSZ-HR25VF (2.5)

Specifications

No specifications.

MXZ Basic Triple Multi-split outdoor unit 5.0 kW (R32) Suitable for: 2x MSZ-HR35VF (3.5 kW) 1X MSZ-HR50VF (5.0) 1X MSZ-HR25VF (2.5)
