Elbow 45° Ø 150-200 mm Double-walled insulated RAL9004

Sale price€139,95
Re-stocking soon

45° bend Ø 150 mm DW insulated black - Specifications

- Double-walled insulated flue pipe, powder-coated RAL 9004
- Inner wall material: stainless steel AISI 316
- Outer wall material: stainless steel AISI 304
- Insulation: 25 mm high-density insulation of 128KG/M3
- Operating pressure: 200 pascal
- Operating temperature: 600 degrees
- Peak temperature: 1000 degrees
- Inner diameter: 150 mm
- Outer diameter: 200 mm
- Heat bridge distance to combustible material: 50 mm
- Suitable for: wood stoves, gas stoves, oil stoves, pellet stoves, coal stoves, ovens
- Incl. clamping band

Legal inspection standard

The Convesa Avant double-wall stove pipe product line has been tested according to EN 1856 -1 standards and the mandatory T600 inspection:
T600-N1-W-V2-L50040/05060-G(50)
The flue pipe thus complies with the standards which are mandatory for the Dutch, Belgian, French and German markets.

Certificate EN 1856 - 1 (EC Certificate)



Product Information

Double-walled insulated chimney pipe, 45° bend, diameter Ø 150mm. Suitable for temperatures up to 600° degrees
